Thickness

EN428

2.0mm  2.5mm  3.0mm

Size

EN426

600*600mm

610*610mm

Weight

EN430

2.0mm: 3.8kg/m2

2.5mm:   4.8kg/m2

3.0mm:   5.8kg/m2

2.0mm:   3.8kg/m2

2.5mm: 4.8kg/m2

3.0mm: 5.8kg/m2

Electric   properties

DIN51953、ASTM F-1550   or NFPA99

Conductive Tile

Dissipative Tile

2.5×104 ～106 ohm

106～109 ohm

Decay   Time

SJ/T10694-2006（lVl〈100V）

EQUAL 0.4S

EQUAL 0.4S

Charge Voltage

SJ/T10694-2006(|V|〈100V）

EQUAL 70

AEQUAL 70

Fire   Resistant Grade

DIN4102

B1

B1

Combustion   Properties

SJ/T11236-2001（＜10S,reach FV-0   level）

EQUAL 0．35s|FV-0

EQUAL 0．35s|FV-0

Amount   of Anti-wear

SJ/T11236-2001(≤0.020g/cm2,100r)

EQUAL 0.014

EQUAL 0.014

Anti-wear   properties

EN660pt2

ITEN-T〈2.0mm3

ITEN-T〈2.0mm3

Wheel   Pressure

EN425

No influence

No influence

Residual   concavity

EN433、DIN51955

0.03mm(2.0mm)

0.035mm(2.5mm)

0.04mm(3.0mm)

0.03mm(2.0mm)

0.035mm(2.5mm)

0.04mm(3.0mm)

Dimensional   Stability

EN433

《0.10%

《0.10%

Color   fastness

IDO105BO2

At least 6

At least 6

Resistance   to chemicals

DIN423、DIN51958

Offers excellent resistance ask for special sheet

Offers excellent resistance ask for special sheet

Impact   sound absorption

VLI、ISO104、ISO717

Approx 2dB

Approx 2dB

Standard for health care facilities NFPA99

Confirms to the requirement of NFPA99 in effect at   the tine of installation
